TCI Maxi Jolly US 1...10 V & Push - LED driver

TCI Maxi Jolly US 1...10 V & Push - LED driver
Zoom image

39,90 EUR

19 % VAT incl. excl. Shipping costs

Shipping time: 2-4 Days* (foreign different)

Product no.: T-122411
Weight: 0.200 kg
For further information, please visit the homepage of this product.

TCI Maxi Jolly US 1...10 V & Push - LED driver

TCI MAXI JOLLY US LED driver; dimmable; 1-10V & Push-Button-funktion; 50W. Constant current and constant voltage are selectable via dip-switch

Now available with noticeable improvements:

  • improved EMC
  • advanced elektrical surge protection up to 3,5-4kV
  • UL certified

Nr. 122410 was replaced by Nr. 122411

Multicurrent-multivoltage converter- universally applicable.
Controll via  1...10V interface or Push-Button.
On/off by a short push. Brightness can be changed by a longer push.

External temperature sensor optional.

Dip-SW Power out Voltage out Current out # LED LED++
Position 1 25 W 74 V max. 350mA const. max 20 max 5
Position 2 35 W 72 V max. 500mA const max 20 max 5
Position 3 39 W  72 V max. 550mA const max 20 max 5
Position 4 46 W  72 V max. 650mA const max 20 max 5
Position 5 50 W 70 V max. 700mA const max 18 max 5
Position 6 50 W 66 V max. 750mA const max 18 max 5
Position 7 50 W 58 V max. 850mA const max 16 max 4
Position 8 50 W 55 V max. 900mA const max 16 -
Position 9 50 W 48 V max. 1,05 A const max 14 -
Position 10 50 W 48V voltage limit settable with Dip-Switch

*all information are supplied without liability

Efficiency depending of the power: 20W - 50W : 84%  - 91%

All tci Jolly converter can be connected to each other via sync-cable. Thus, the control over only one button is possible.
Maximum 10 drivers synchronization, is possible command only one driver (1 Master + 9 Slaves).
Button and installation materials are not included in delivery.

For detailed description please refer to the data sheet.

Data sheet and wiring (PDF) download
