ATRIUM RONQ LED downlight 35W ZigBee/DALI DT8/Casambi
€486.71*
net-price: €409.00Currently not available - Contact us now!
- Purchase and advice from the LED expert
- Professional products from over 15 years of experience
- LED technology is our passion
- Free shipping for orders over €150 (DE)
Product information "ATRIUM RONQ LED downlight 35W ZigBee/DALI DT8/Casambi"
PI-LED downlight ATRIUM RONQ 35W - dimming via DALI DT8 or NeoLink / ZigBee, up to IP54
This round recessed luminaire has PI-LED technology, which combines Tuneable White and RGB in one light source. This means that ATRIUM RONQ can cover a wide color temperature range from 1800 K to 16000 K and thus precisely reproduce the course of daylight. This is supported by the uniform light distribution that emanates from the luminaire. In addition, the LED downlight is very robust, which can be attributed to a high degree of protection up to IP54.
Another highlight are the innovative control options of the ATRIUM RONQ:
- Smart lighting control with NeoLink / ZigBee
- Control of complex lighting systems with DALI DT8 < / a>
- series of measurements with the PI-LED spots from Kiteo
- Control via Casambi
Product overview and features:
- Round downlight with automatic daylight sequence
- Matt reflector with diffuser
- Soft light mixture and even light distribution
- Range of functions: Color temperature 1,800 K to 16,000 K
- High color locus stability thanks to microcontroller-controlled LED management
- Temperature compensation
- Factory calibration
Ordering data for ATRIUM RONQ:
The product is available in three different installation sizes. There is also the option of choosing between the ultra-modern control options DALI DT8, Casambi and ZigBee. Depending on the application (indoor / outdoor), versions with degrees of protection IP40 and IP54 are available.
Technical data:
| Design | Small (Ø 154 mm) | Middle (Ø 204 mm) | Large (Ø 254 mm) |
| light source | LED module (PI-LED) | ||
| Operating voltage | 230 VAC | ||
| Performance | 20 W | 25 W | 35 W |
| Beam angle | 75 ° | 82 ° | 80 ° |
| luminous flux | 1200 lm | 2000 lm | 2500 lm |
| Color temperature | 1800 K - 16000 K | ||
| Color rendering index (CRI) | > 90 | ||
| Control | NeoLink / ZigBee DALI DT8 Casambi | ||
| Dimming range | CCT / CIE-xy 5-100% RGB 0-100% | ||
| Degree of protection | IP40 or IP54 | ||
| Protection class | SKII | ||
| Lifetime | L80 / B10 50000 h | ||
| Housing color | white (RAL 9003) | ||
| Assembly | installation | ||
| Dimensions | Ø 154 mm x 97 mm | Ø 215 mm x 107 mm | Ø 265 mm x 127 mm |
Note:
The products of the manufacturer Kiteo are individually tailored to suit your needs. Made especially for you according to your specification. This also explains the longer delivery time of 1-3 weeks depending on the workload.
For more information, please refer to the data sheet in the download tab.
| ·Application/IP-Code: | IP4x, IP5x |
|---|---|
| ·Color Temperature/Color: | 2700K, 3000K, 3500K, 4000K, >5000K, Tuneable White |
| ·Dimmable/Control: | DALI DT8, Zigbee |
KITEO GmbH
is a company that offers lighting solutions that revolve around the relationship between light and people, i.e. ambience and a feel-good atmosphere take centre stage and the lighting is geared towards your needs. KITEO relies on innovative PI-LED technology, which combines Human Centric Lighting and brilliant RGB colour effects in one colour source and brings daylight into every room in its natural course.
For more than 10 years we have been offering products from the manufacturer KITEO worldwide. Below is our portfolio of products. Tip: Use the filter function to quickly find the driver you need, or give us a call.
KITEO GmbH & Co.KG
Landsberger Str. 310 - 80687 München - Germany
E-Mail: info@kiteo.eu
Login
- Hole diameter - We recommend selecting the spots first, then drilling the holes. Otherwise the limitation is predetermined Output
- Light output in lumens, or wattage. How much light is needed in the room. There is no general answer to this question. Use the following link for the project enquiry
- Installation depth - usually a mandatory requirement in terms of drill hole depth or distance from suspended ceiling.
- Color temperature dimmability - We recommend modern options such as DALI or Casambi.
- Beam angle - For uniform room illumination. Usually determined by the distribution of the spots in the room and the room height.
- Fastening - Installation in false ceiling or concrete ceiling Glare - Depending on the viewing angle, lower LEDs in the spotlight can often no longer be perceived as a bright point of light, thus ensuring pleasant lighting.
If you have a lighting project and would like to use downlights, please use the link provided for our project enquiry form. We will try to answer all your questions.
