LED downlight IP54 fixed single reflectors

A++ to A
From 43.50€ *
Net price: 37.50€

Prices incl. VAT plus shipping costs

Please select a variant first

Power:

color temperature:


piece

  • 1794-EVA-10-WW1
  • EVA-10WW1
  • 0.27 kg
  • ALS GmbH
LED downlight with fixed single reflectors DThe LED downlight EVA is ideal for office and... more

LED downlight with fixed single reflectors

DThe LED downlight EVA is ideal for office and communication areas. In addition, you can use this downlight due to the optimal glare in many required areas.
An efficient look in the new design provides the best possible glare reduction. Due to 3 different sizes, this  LED Downlight IP54 can be used flexibly. The low installation depth and the integrated LED driver make installation very easy. The lamp works flicker-free.


Our LED downlight with fixed single reflectors in IP54 is available in the following versions

  • Available in three different capacities
  • Aviable in  3000K (warm white) and  4000K (neutral white)
  • Beam angle of 90 °
  • Even light distribution
  • UGR < 19
  • CRI > 80
  • Supply voltage 230 V
  • Integrated LED driver
  • Immediate start
  • Service life > 35,000 h
  • Front IP54 (with closed ceiling)
  • Low installation depth
Type

EVA-10-NW1

EVA-10-WW1

EVA-18NW1

EVA-10WW1

EVA-25NW1

EVA-25WW1

Color temperature (CCT)

4000K

3000K

4000K

3000K

4000K

3000K

Luminous flux

1003lm

987lm

1945lm

2050lm

2858lm

2855lm

Power

10W

18W

25W

Mounting depth

40mm

40mm

40mm

Outer diameter

110mm

190mm

228mm

Wall and ceiling detail

95mm

165mm

205mm

Color (housing)

white

white

white

Weight 0,263 kg 0,558 kg 0,808 kg

For further information please refer to the data sheet. (Download-Tab)
Related links to "LED downlight IP54 fixed single reflectors"
Flicker-free recessed luminaire with integrated LED driver. Flexible and low installation depth more
Features/tags of this product family. Please refer about the details in the description or datasheet.
Power: 10W, 20W, 25W
Hole diameter: 95mm, 165mm, 200mm
Color Temperature/Color: 3000K, 4000K
Data sheet EVA-10-NW1
Data sheet EVA-10-WW1
Data sheet EVA-18-NW1
Data sheet EVA-18-WW1
Data sheet EVA-25-NW1
Data sheet EVA-25-WW1
