K-MOTUS Pendant LED Pendant Luminaire with PI-LED Module 670lm

KITEO K-Motus PI-LED Pendant LED Pendant Luminaire

Daylight-like pendant luminaire with PI-LED technology: color temperatures from 1,800 K to 16,000 K for biologically effective lighting with high color point stability and modular dimmability.

LED pendant luminaire with color temperature range 1,800–16,000 K, 670 lm luminous flux, dimmable 1–100%, ZigBee/DALI controllable, 50,000 h lifespan.

Key Features

• Color temperature range 1,800 K to 16,000 K – Replicates the natural daylight cycle for enhanced well-being and vitality – from warm evening light to daylight-like illumination.
• 670 lm luminous flux at 15 W power consumption – Efficient illumination with low energy consumption for offices and residential environments.
• 1–100% dimming range with Modular Dimming and Camera Ready – Flexible brightness adjustment and camera compatibility for broadcast and film production without flicker.
• ZigBee and DALI DT8 control – Wireless and wired control for intelligent lighting management systems and seamless integration into existing infrastructures.
• Lifespan L80/B10 50,000 h – Maintenance-free long-term operation with minimal replacement costs over many years.
• PI-LED LMU 2.0 with melanopic efficacy factor – Biologically effective lighting that supports the circadian rhythm and promotes the natural sleep-wake cycle.
• Highly stable color consistency through microcontroller control – Uniform and consistent light mixing without color shift throughout the entire service life.
• Aluminum housing in white (RAL 9003), black (RAL 9005) or grey – Elegant design options for a wide range of interior concepts and architectural applications.

Application Areas

Office and Workplace Lighting

Daylight-like illumination with adjustable color temperature enhances concentration and productivity. The biologically effective PI-LED technology supports the natural circadian rhythm and reduces fatigue during screen-based work.

Broadcast and Film Production

The Camera Ready function and flicker-free dimming (1–100%) enable professional video recordings without artifacts. The color temperature range from 1,800–16,000 K covers virtually every lighting scenario.

Healthcare and Wellness Facilities

The melanopic efficacy factor and daylight simulation promote well-being and support therapeutic lighting applications in hospitals, medical practices and wellness environments.

Retail and Exhibition Spaces

Flexible color temperature selection and a high luminous flux of 670 lm ensure optimal product presentation and efficient room illumination using energy-saving LED technology.

Residential Spaces and Design Interiors

The elegant pendant design with continuously adjustable color temperature creates individual lighting atmospheres – from cozy warm white to invigorating daylight.

Technical Specifications

K-Motus PI-LED Pendant LED Module PI-LED

*Grey finish: available with DALI or ZigBee as suffix -GR

Product Benefits in Detail

PI-LED Technology with Biologically Effective Lighting

The PI-LED LMU 2.0 version combines RGB colors with daylight-like characteristics and integrates a melanopic efficacy factor (alpha smel). This enables biologically effective lighting that supports the circadian rhythm and promotes well-being – without UV or infrared radiation. The technology replicates the natural course of daylight and creates lighting experiences that enhance vitality and health.

Color Consistency and Light Quality

Microcontroller-controlled LED management ensures consistent color stability throughout the entire service life. Smooth color mixing and uniform light distribution provide flicker-free, comfortable illumination. Photometric tolerances are within ±15%, ensuring consistently high quality.

Intelligent Control and Integration

The K-MOTUS Pendant supports ZigBee for wireless control (NeoLink) and DALI 2 with DT8 registration for wired lighting systems. Modular Dimming and the Camera Ready function enable professional use in broadcast and film production. Over-the-bus updates allow firmware updates without physical access to the luminaire.

Robust Design and Long-Term Reliability

The aluminum LMU housing with strain relief provides mechanical stability and Protection Class I. The non-replaceable light source is fully integrated into the luminaire, minimizing maintenance requirements. With a service life of 50,000 h (L80/B10) and a permissible operating temperature of 10–35 °C, the luminaire is designed for long-term professional use.

Austrian Manufacturing Quality

KITEO stands for planning, development and manufacturing from a single source in Austria. With over 30 years of experience and maximum precision, lighting solutions are created that meet European quality standards and have proven themselves in large-scale projects such as Vienna General Hospital (AKH).

Variants & Options

Available housing colors: White (RAL 9003), Black (RAL 9005), Grey (on request). Suspension length: 150 cm, luminaire length: 30 cm. Available with either ZigBee (wireless) or DALI DT8 (wired) control.

Typical Applications

Modern office buildings with daylight-like lighting to increase employee productivity; television studios and film productions requiring flicker-free recording with Camera Ready functionality; wellness and healthcare facilities using circadian lighting concepts; retail spaces with flexible product presentation through adjustable color temperatures.

About KITEO

KITEO is an Austrian manufacturer with more than 30 years of experience in lighting development. The K-MOTUS Pendant is designed, developed and manufactured in Austria to deliver maximum quality and flexibility. The proprietary PI-LED technology with melanopic efficacy combines daylight-like illumination with biologically effective lighting. KITEO solutions have been successfully implemented in large-scale projects throughout Europe and can achieve energy savings of up to 60% compared to conventional lighting systems.

Safety Information, Certificates & Warranty

Protection Class I. Operating voltage: 230 VAC. IP20 protection rating. Permissible operating temperature: 10–35 °C. Photometric data are subject to a tolerance of ±15%, electrical data to ±15%. Light source is not replaceable. Weight: 1 kg. Technical certifications according to applicable EU directives are available.

Note:
Products from this manufacturer are individually manufactured according to your specifications. As a result, delivery times are typically between 1 and 3 weeks, depending on current production capacity.
