Constant current dimmer via DALI for RGB/W LEDs (colour control)
For the direct control of RGB/W LED modules with current input via DALI address (DT8).
The DALI Dimmer RGB/W by Lunatone makes a colour control in accordance with the DALI specification for Device Type 8 possible, Colour Type RGBWAF and offers a separated control feature of brightness and colour (operating mode: Normalized, Unlinked).
Lunatone offers 2 housing forms, with variants up to 350mA in a small housing, up to 1000mA in a big housing.
Supply voltage 12V to 48V DC with integrated short protection.
The configuration happens via DALI cockpit and DALI USB interface.
The following versions are available:
RGB three channel versions, with a DALI address
With collective plus pole: 86458913-350
With collective minus pole: 86458913-350GM
Up to max. 3x 700mA Output current
With collective plus pole: 86458913-700
With collective minus pole: 86458913-700GM
RGBW four channel versions, with a DALI address
With collective plus pole: 86458912-350
With collective minus pole: 86458912-350GM
Up to max. 4x 700mA output current
With collective plus pole: 86458912-700
With collective minus pole: 86458912-700GM
Other technical data:
- Control input: DALI
- Condition after return: depending on the DALI settings
- Supply: 12VDC-48VDC
- Output voltage range: 3V-45V (with 48V supply)
- Temperature: -20 °C - 60 °C
- Protection type: IP20
- Max. wir cross-section: up to 2,5mm²
- Dimension (LxWxH): check data sheet
|Application/IP-Code:||IP20 - IP44 (Indoor)|
|Constant Current:||0,7A, 0,35A|
|Dimmable/Control:||DALI, DALI DT8|
|Color Temperature/Color:||RGB/3-Ch, RGBW/4-Ch|
