KNX 4 channel LED dimming sequencer 5A

Product information "KNX 4 channel LED dimming sequencer 5A"

The Enertex® KNX 4-channel LED dimming sequencer 5A is a pulse width modulating dimmer and sequencer for LED strips, LED spots and LED lights for constant input voltage 12 - 24VDC.

Attention: This Product is not in Production anymore. Successor is Article 1174.

  • Four dimming channels, pulse width modulated, max. 5 A per channel
  • Optimal load distribution of the channels within a PWM period enables, among other things, the efficient use of tunable white lamps and reduces the switching load on the upstream LED power supplies
  • Variable voltage input and output 12 - 24V
  • Integrated bistable 230 VAC relay 16 A, inrush 165A@20ms, 800A@200µs
  • Integrated protection against overvoltage, overcurrent, undervoltage, overtemperature, reverse polarity
  • Commissioning button for quick testing of the wiring
  • Dimmer addressable in RGB mode or HSV color space mode
  • Four different dimming characteristics to choose from with integrated soft dimming function
  • Automatic switching on/off of the relay with two configurable blocking times
  • Integrated Scenes and Bitscenes
  • 16 predefined and five freely definable sequences
  • Free configuration of the channels:
    • Four independent channels
    • Two channels white&rszlig; (cold white / warm white)
    • One Channel Whiteß (cold white / warm white), two independent channels
    • One channel color (RGBW)
    • One color (RGB) channel, one independent channel
  • Diagnostics/reporting of the protective functions via KNX group addresses
  • PWM switchable between 488 and 600 Hz
  • REG version - DIN rail housing with 4 HP

See our download tab for more information.

Properties "KNX 4 channel LED dimming sequencer 5A"
·Application/IP-Code: IP20 - IP44 (Indoor)
·Color Temperature/Color: RGB/3-Ch, RGBW/4-Ch, Tuneable White
·Constant Voltage: 12V, 24V
·Dimmable/Control: KNX
·Lamp shape: DIN Rail, Recessed ceiling
Manufacturer "Enertex Bayern GmbH"

EnertexBayern GmbH is simulation, developpment and consulting. The cumulative know-how you find in every high quality product of this Company.

Related links of the manufacturer

Enertex® KNX 4Kanal LED dimming sequencer 5A REG data sheet/brochure
1160 Brochure
