TCI driver Mini MD / Mini MD BI
Net price: 20.83€
Net price: 20.83€
Prices incl. VAT plus shipping costs
Please select a variant first
- Order number: 760-127030
- Hersteller-Nr.: 127030
- Weight: 0.12 kg
- GTIN/EAN: 8010703361751
- Manufacturer: TCI TELECOMUNICAZIONI ITALIA S.R.L.
TCI MINI MD and MINI MD BI LED-driver with leading edge/trailing edge dimming Very small... more
TCI MINI MD and MINI MD BI LED-driver with leading edge/trailing edge dimming
- Very small constant current driver
- Constant current driver available with different output currents
- Driver for indoor use, degree of protection: IP20
- Protection class: II (protection against direct or indirect contact) - MINI MD versions
- Protection class: I and II - versions MINI MD BI
- Protection against overheating and short, voltage peaks and overload.
- 8 variants with 250 mA, 350 mA, 500 mA and 700 mA each available as MINI MD or MINI MD BI (built-in version).
The special feature of this constant current driver is amplitude dimming (linear, non PWM) for the LED current. That is a very impressive feature for phase dimming drivers and creates flickerfree light. Also usable for Dim2warm LEDs.
The TCI MINI MD and TCI MINI MD BI are driver with leading edge/trailing edge dimming.
|Typ||MD250 (BI)||MD350 (BI)||MD500 (BI)||MD700 (BI)|
|Partnumber||127036 (127037)||127030 (127031)||127032 (127033)||127034 (127035)|
|Output coltage||25-50 VDC||25-51 VDC||16-42 VDC||16-28 VDC|
|Output current||250 mA||350 mA||500 mA||700 mA|
|Max. output voltage||59 VDC||59VDC||50VDC||50VDC|
For more information please refer to the data sheet in the Download Tab.
Related links to "TCI driver Mini MD / Mini MD BI"
Small LED driver (12,5-21W) with leading edge/trailing edge dimming. TCI Mini MD is available... more
Features/tags of this product family. Please refer about the details in the description or datasheet.
|Constant Current:||0,5A, 0,7A, 0,35A|
|Power range:||5 - 20 W|
|Dimmable/Control:||Linear/AM, Phase-Cut (Triac)|
|#Kategoriefilter:||LED-Treiber-alles mit CC|
