Zigbee Dimming Actuator Mini

69.40€ * 116.62€ * (40.49% saved)
Net price: 58.32€

Prices incl. VAT plus shipping costs

Ready to ship today,
Delivery time appr. 1-3 workdays*

  • 57006000
  • 57006000
  • 0.06 kg
  • 4250582502966
  • Insta GmbH
Zigbee Dimming Actuator Mini   Universal dimming actuator for dimming of light e.g.... more

Zigbee Dimming Actuator Mini



Universal dimming actuator for dimming of light e.g. for LED lights, high- and low-voltage halogen lamps in a Zigbee 3.0 system. It operates according to the leading edge phase control or trailing edge phase control principle and automatically sets the dimming principle suitable for the connected load. The device provides one input for connecting a push-button.

Configuration and immediate function test via the Prog. button. It is installed in the appliance box behind the switch or pushbutton.

Product features

  • Zigbee Actuator to integrate with all Zigbee systems with Zigbee 3.0 Standard
  • Dimming actuator for all standard lamps
  • Dimming using the phase cut-on and cut-off principle
  • Automatic or manual load setting in the appropriate dimming mode
  • Parameterisation via NEXENTRO Confi g App
  • Updateable via NEXENTRO Config App
  • Installation in appliance boxes behind push-buttons
  • Input for connecting a push-button
  • Display of the selected operating mode
  • Activation through bulb-preserving soft -start
  • Electronic short-circuit protection with permanent shutdown aft er 7 seconds
  • Electronic excess temperature protection
  • Screw terminal for the through-wiring of existing conductors (max. 16 A)
  • Button and LED for commissioning and functionality Tests


Technical Data Zigbee Dimming Actuator Mini

Mains voltage AC 230 / 240 V ~
Mains frequency 50 / 60 Hz
Connected load of incandescent lamps 20 ... 140 W
Connected load HV LED leading edge phase control typ. 3 ... 20 W
Connected load HV LED trailing edge phase control typ. 3 ... 200 W
Standby Power consumption max. 0,2 W
Power loss max. 1,7 W
Ambient temperature -5 ... +45 °C
Storage/transport temperature -25 ... +70 °C
Dimensions (LxWxH) ca. 48 x 45 x 20 mm
Zigbee
Communication protocoll Zigbee 3.0 (Router)
Radio frequency 2,400 ... 2,483 GHz
Transmission capacity 1 mW
Bluetooth
Radio frequency 2,400 ... 2,480 GHz
Transmission capacity max. 2 mW, Class 2
Transmitting range typ. 10 m

Nexentro Apps:

google download nexentro apple download nexentro

Related links to "Zigbee Dimming Actuator Mini"
Universal dimming actuator for dimming of light e.g. for LED lights, high- and low-voltage... more
Features/tags of this product family. Please refer about the details in the description or datasheet.
Application/IP-Code: IP20 - IP44 (Indoor)
Lamp shape: Socket installation
Power: 100 - 250 W
Dimmable/Control: Phase-Cut (Triac), Zigbee
Datasheet Zigbee Dimmer
Nexentro 57006000
Usermanual
Zigbee Universaldimmer
