Downlight PASSUM UP 11W

Variants from 473.03€ *
Net price: 397.50€

Prices incl. VAT plus shipping costs

Please select a variant first

Version:

Color:

Colour temperature:


piece

  • 4501-WW-MG-R
  • PASUP180-11WW7
  • 2.69 kg
  • ALS GmbH
LED Recessed floor luminaire PASSUM UP 11W from A.L.S. These recessed luminaires optimally... more

LED Recessed floor luminaire PASSUM UP 11W from A.L.S.

These recessed luminaires optimally meet the requirements for upwards or downwards illumination. The innovative technology and the variety of combinations are to be emphasized here.
The recessed luminaires are corrosion-resistant and passable with exchangeable covers, which impress with their versatile installation options.
The luminaire housings with LED or conventional lamps can be swiveled or adjusted, thus allowing the inclination of the light for perfect illumination of the surfaces.


Features of the PASSUM-UP series:

  • Structure: Luminaire housing made of primary aluminum with reduced copper content, painted with anti-corrosive polyester powder after phosphorus chromating
  • Tempered, transparent glass T = 40 ° C; Thickness from 6 to 12 mm and max. Load of 2,000 to 3,500 kg
  • 0.5 m floor-retractable H07RN-F cable with IP68 connection
  • Built-in box made of stabilized technopolymer
  • The covers are available in: round with primary aluminum with double coating; round and square made of INOX AISI 316L stainless steel with stainless steel hexagon screws
  • Manufactured in accordance with European standards EN 60598-1: 2015
  • Version is available in round and square

Technical data:

Light source LED LED
Colour temperature 3000K 4000K
Beam angle 38°
pivoted 15°
System power 11W
Connection voltage 230 V
Luminous flux 1060 lm
Colour rendering index CRI >80
Protection class 1
Mechanical  load IK10
passable 3500Kg
Protection type IP67
Lifespan L80 B20; 60.000 h
Dimensions round Ø180mm
Square 180mm x 180mm

INFO: incl. Luminaire housing, cover, external driver, floor-mounting box and longitudinal connector

For further information please refer to the data sheet in the Download-tab.

Related links to "Downlight PASSUM UP 11W"
11W LED recessed floor light with IP67, round / square version; metallized grey / stainless... more
Features/tags of this product family. Please refer about the details in the description or datasheet.
Application/IP-Code: IP65/67 (Outdoor)
Lamp shape: floor installation
Color Temperature/Color: 3000K, 4000K
Data sheet round grey
Data sheet round stainless steel WW
Data sheet round stainless steel NW
Data sheet square stainless steel WW
Data sheet square stainless steel NW
