Downlights PASSUM UP 4W

A++ to A
From 258.32€ *
Net price: 222.69€

Prices incl. VAT plus shipping costs

Please select a variant first



color temperature:


  • 4494-WW-MG-R
  • PASUP125-4WW7
  • ALS GmbH
LED Recessed floor luminaire PASSUM-UP 4W from A.L.S. These recessed luminaires optimally meet... more

LED Recessed floor luminaire PASSUM-UP 4W from A.L.S.

These recessed luminaires optimally meet the requirements for upwards or downwards illumination. The innovative technology and the variety of combinations are to be emphasized here.
The recessed luminaires are corrosion-resistant and passable with exchangeable covers, which impress with their versatile installation options.
The luminaire housings with LED or conventional lamps can be swiveled or adjusted, thus allowing the inclination of the light for perfect illumination of the surfaces.

Features of the PASSUM-UP series:

  • Structure: Luminaire housing made of primary aluminum with reduced copper content, painted with anti-corrosive polyester powder after phosphorus chromating
  • Tempered, transparent glass T = 40 ° C; Thickness from 6 to 12 mm and max. Load of 2,000 to 3,500 kg
  • 0.5 m floor-retractable H07RN-F cable with IP68 connection
  • Built-in box made of stabilized technopolymer
  • The covers are available in: round with primary aluminum with double coating; round and square made of INOX AISI 316L stainless steel with stainless steel hexagon screws
  • Manufactured in accordance with European standards EN 60598-1: 2015
  • Version is available in round and square

Technical data:

Light source LED LED
Colour temperature 3000K 4000K
Beam angle 38°
pivoted 15°
System power 4W
Connection voltage 230 V
Colour rendering index CRI >80
Protection class 1
Mechanical  load IK10
passable 2000Kg
Protection type IP67
Lifespan L80 B20; 60.000 h
Dimenions round Ø125mm
square 125mm x 125mm

INFO: incl. Luminaire housing, cover, external driver, floor-mounting box and longitudinal connector

For further information please refer to the data sheet in the Download-tab.

Related links to "Downlights PASSUM UP 4W"
4W LED recessed floor light with IP67, round / square version; metallized grey / stainless steel,... more
Features of the product family. Details on variants can be found in the description.
Constant Voltage: 24V
Application: IP65/67 (Outdoor)
Color Temperature/Color: 3000K, 4000K
Data sheet round
Data sheet square
Photometric Data LDT
