LED recessed office downlight 170 mm UGR

Product information "LED recessed office downlight 170 mm UGR "

LED recessed office downlight 18W, glare-free BILTON LEDON

This high-quality and innovative LED recessed downlight from the manufacturer BILTON LEDON with aluminium reflector and white frame has an excellent glare value of UGR<19 and is therefore ideal for lighting rooms where a glare-free environment is important. These include office and conference rooms, sales rooms, corridors, foyers and living Areas.

Features:



Technical data of the LED downlight:

Colour temperature4000K (Neutral White)
Luminous Flux1800 lm
Colour Rendering Index Ra>90
System efficacy100 lm/W
System performance 18W
UGR< 19 UGR
Beam Angle60°
Protection typeIP44 on room side, IP20 on ceiling side
Housing materialAluminium / PC
FinishRound, white (RAL9016)
External dimensions170 x 112
Mounting dimensionsØ 140-140 mm
Weight0,6 kg

Note on the predecessor: This downlight is the successor to the LEDON NEWTON Office recessed downlight UGR <19 Article number.


Further technical data for this LED recessed downlight can be found in the datasheet in the Download tab.

Properties "LED recessed office downlight 170 mm UGR "
·Color Temperature/Color: 4000K
·Dimmable/Control: DALI, Push-Button
·Hole diameter: 150mm, 160mm, 165mm
·Lamp shape: Recessed ceiling
Manufacturer "BILTON LEDON Technology GmbH"

Started as a daugther company of Zumtobel. Today, independent and famous manufacturer known for premium quality of LED lamps. LED lamps from BLT convince with excellent colour rendering close to that of the well-known incandescent lamp.

Related links of the manufacturer

Data sheet Office Downlight
Instruction manual Office Downlight

0 of 0 reviews

Leave a review!

Share your experiences with other customers.


In nachfolgenden FAQs finden sich weitere hilfreiche Informationen zur richtigen Auswahl

Recessed ceiling spotlights/downlights are available in many different versions. These parameters primarily define this product family:
  • Hole diameter - We recommend selecting the spots first, then drilling the holes. Otherwise the limitation is predetermined Output
  • Light output in lumens, or wattage. How much light is needed in the room. There is no general answer to this question. Use the following link for the project enquiry
  • Installation depth - usually a mandatory requirement in terms of drill hole depth or distance from suspended ceiling.
  • Color temperature dimmability - We recommend modern options such as DALI or Casambi.
  • Beam angle - For uniform room illumination. Usually determined by the distribution of the spots in the room and the room height.
  • Fastening - Installation in false ceiling or concrete ceiling Glare - Depending on the viewing angle, lower LEDs in the spotlight can often no longer be perceived as a bright point of light, thus ensuring pleasant lighting.

If you have a lighting project and would like to use downlights, please use the link provided for our project enquiry form. We will try to answer all your questions.
