K-CIRCUM - round light with PI-LED technology

€1,451.56*

net-price: €1,219.80

Content: 1 Stück

Prices incl. VAT plus shipping costs

delivery time 5-10 Working days*

Product number: KCIRCUM-45-A-CA-S-DI

Manufacturer: KITEO GmbH

Weight: 6.85 kg

Min. order quantity: 1

Our benefits

Purchase and advice from the LED expert
Professional products from over 15 years of experience
LED technology is our passion
Free shipping for orders over €150 (DE)

Product information "K-CIRCUM - round light with PI-LED technology"

Kiteo K-CIRCUM round light with PI-LED technology

The Kiteo K-CIRCUM impresses in every interior thanks to the latest PI-LED technology. Large-area lighting in 1,800 - 16,000K is no problem.

Ideal use for large-area lighting in the interior.
Color temperature 1,800K to 16,000K with high
Color locus stability through microcontroller-controlled0
LED management (with temperature compensation and factory calibration).
Monitoring of the operating temperature with automatic dimming protection function.
Direct 230 V mains connection.
Assembly: structure | pendulum
Control via: DALI DT8, Neolink/Zigbee and now also via CASAMBI!

Technical data

Light source	LED module PI-LED
Power S / M / L	63W - 117W
Luminous flux	3800lm - 9700lm
color temperature	1800K - 16000K
Colour rendering index	89 (@4,000K)
degree of protection	IP 20
Dimming range	1-100%
Lifetime	L80/B10 50,000h
Tests / Approvals	CE / RoHs compliance
Weight	6.8kg / 13.6kg / 26kg
Operating voltage	230VAC
Control	ZigBee, DALI DT8
Protection class	I
Montage	Construction / Pendulum

For more data see our download tab.

Properties "K-CIRCUM - round light with PI-LED technology"

·Application/IP-Code:	IP20 - IP44 (Indoor)
·Color Temperature/Color:	2700K, 3000K, 3500K, 4000K, >5000K, HCL/PI-LED, RGB/3-Ch, RGBW/4-Ch, Tuneable White
·Dimmable/Control:	DALI, DALI DT8, Zigbee
·Lamp shape:	Ceiling/wall mounting, Pendelum Suspension
·Power range:	50 - 100 W, 100 - 250 W

Manufacturer "KITEO GmbH"

KITEO lighting solutions revolve around the relationship between light and people, i.e. Ambience and a feel-good atmosphere take center stage and the lighting is based on your needs. KITEO makes use of the innovative PI-LED technology that unites Human Centric Lighting and brilliant RGB colour effects in one light source and brings daylight into every room while simulating the natural circadian daylight sequence.

Related links of the manufacturer

Manufacturer website

Kiteo K-CIRCUM datasheet

No reviews found. Share your insights with others.

In nachfolgenden FAQs finden sich weitere hilfreiche Informationen zur richtigen Auswahl

Where can I get support and advice on recessed ceiling spots/downlights?

Recessed ceiling spotlights/downlights are available in many different versions. These parameters primarily define this product family:

Hole diameter - We recommend selecting the spots first, then drilling the holes. Otherwise the limitation is predetermined Output
Light output in lumens, or wattage. How much light is needed in the room. There is no general answer to this question. Use the following link for the project enquiry
Installation depth - usually a mandatory requirement in terms of drill hole depth or distance from suspended ceiling.
Color temperature dimmability - We recommend modern options such as DALI or Casambi.
Beam angle - For uniform room illumination. Usually determined by the distribution of the spots in the room and the room height.
Fastening - Installation in false ceiling or concrete ceiling Glare - Depending on the viewing angle, lower LEDs in the spotlight can often no longer be perceived as a bright point of light, thus ensuring pleasant lighting.

If you have a lighting project and would like to use downlights, please use the link provided for our project enquiry form. We will try to answer all your questions.
