Linea DS-A 195 Adjustable

Product information "Linea DS-A 195 Adjustable"

Illuxtron Linea DS-A 195 Downlight

The latest generation of high performance "Chip-on-Board" (COB) LEDs.

TE Connectivity

The patented COB-LED connector ensures optimum heat dissipation through the heat sink during its entire service life.

Front protection glass

It has been proven that corrosion, smoke and dust deposits on the mirror of an LED luminaire can cause a loss of up to 50% of the light output over time. Illuxtron COB-LEDs are equipped with a front protection glass that reliably protects the LED and the reflector mirror from environmental influences and guarantees a lifetime of high performance.

3-Phase-Adapter

The Odion and Linea Track spots are equipped with a 3-phase adapter from Nordic Aluminium. The additional retaining clip on the mounting device holds the light firmly in place on the track and even allows vertical wall mounting.

Special features and characteristics

  • Attractive price-performance ratio
  • Various light colours, beam angles and CRI options
  • Excellent thermal conductivity over the entire service life
  • Latest generation of high-power „Chip on Board“ (COB)-LEDs
  • Front glass protects the reflector against dust and smoke deposits
  • Maximum temperature of the body under 70°C; C
  • power supplies ENEC/EMC compliant
  • Active power factor correction (PFC)
  • Electronic components in A-brand quality

The most important technical details of the Linea DS-A 195 series:

Housing colour

matt white RAL 9016 (XX=MW)
matt black RAL 9005 (XX=BL)

MaterialHousing: Die-cast aluminium
Reflector glass: Polycarbonate
Dimensionsø 140 mm
Required installation depth> 109 mm
Ceiling cut-out

195 mm: For soft mineral fibre ceilings we recommend the use of a wooden board or a ceiling ring on the back of the board

UseageIndoors
Beam angle (FWHM)18° / 37° / 60°
CRI / Ra (typ.)80 / 97
Colour Consistency (MacAdam)SDCM3
IP CodeIP20 / IP44
IK CodeIK03
Operating temperature (Ta)-20°C / +45°C
Lifetimeat 25°C
L70B50165.000 h
L80B50105.000 h
L90B5051.000 h
Safety signsEN60598 / EN62031 / EN62471
EMC DirectiveEN55015
Guarantee7 Jahre
Energy classA+

Linea Linea DS-A 195

The driver is already available for this downlight.

For further information on Linea DS-A 195 downlights, please refer to the respective data sheet.

Dimmbarkeit

No (*Note)

Artikelnummer130603XXCA02130603XXCR02130603XXCG02130603XXFD02130603XXCD02130603XXCU02
Farbtemperatur3000 K4000 K
UGR17,917,717,315,718,117,2
Lichtstrom3000 lm5000 lm2500 lm3750 lm3400 lm5700 lm
Lm/W (mit EVG)1081009075122114
TypInkl. PSU
Leistung32,1 W27,0 W57,2 W50,5 W27,0 W50,5 W
SchutzklasseII
Pf0,950,980,950,980,950,98

*Note: This table shows only the switchable version with the 18° beam angle. This downlight is also available as dimmable version as DALI and 1-10V&Push, as well as different mounting options and with a beam angle of 37° or 60°.


For data sheets of the downlights Linea DS-A 195 series, see Download Tab:

Note:
The products of the manufacturer Illuxtron are individually manufactured according to your specification especially for you. This also explains the longer delivery time of 1-3 weeks depending on capacity utilisation.

Properties "Linea DS-A 195 Adjustable"
·Application/IP-Code: IP20 - IP44 (Indoor)
·Color Temperature/Color: 3000K, 4000K
·Dimmable/Control: 1..10V, DALI
·Hole diameter: 195mm
Manufacturer "Illuxtron International BV"

The Dutch company Illuxtron International and the Austrian company Bartenbach have joined together in 2015 to develop new products in the field of reflector technology. Both R & D departments participated in the development of "Dark Light" reflectors for the mini downlights and Aviora panels.

Related links of the manufacturer

Datasheet Illuxtron

Linea DS-A 195

0 of 0 reviews

Leave a review!

Share your experiences with other customers.


In nachfolgenden FAQs finden sich weitere hilfreiche Informationen zur richtigen Auswahl

Recessed ceiling spotlights/downlights are available in many different versions. These parameters primarily define this product family:
  • Hole diameter - We recommend selecting the spots first, then drilling the holes. Otherwise the limitation is predetermined Output
  • Light output in lumens, or wattage. How much light is needed in the room. There is no general answer to this question. Use the following link for the project enquiry
  • Installation depth - usually a mandatory requirement in terms of drill hole depth or distance from suspended ceiling.
  • Color temperature dimmability - We recommend modern options such as DALI or Casambi.
  • Beam angle - For uniform room illumination. Usually determined by the distribution of the spots in the room and the room height.
  • Fastening - Installation in false ceiling or concrete ceiling Glare - Depending on the viewing angle, lower LEDs in the spotlight can often no longer be perceived as a bright point of light, thus ensuring pleasant lighting.

If you have a lighting project and would like to use downlights, please use the link provided for our project enquiry form. We will try to answer all your questions.
