TCI MP 32 K2 - LED driver

36.31€ *
Net price: 30.51€

Prices incl. VAT plus shipping costs

Ready to ship today,
Delivery time appr. 1-3 workdays*


TCI MP32 K2 LED driver; 32W; TCI 122200; Constant voltage, constant current are adjustable via... more

TCI MP32 K2 LED driver; 32W; TCI 122200; Constant voltage, constant current are adjustable via dip-switch.

Multicurrent-multivoltage converter- universally applicable.

By varying the dip switch settings, it is possible to choose between six constant currents and three constant voltages.
Flicker ( Output Ripple ) <= 3%

Konstantspannung und Konstantstrom

Dip-SW Power out Voltage out Current out # LED
Position 1 15 W 47 V max 350mA const max 12
Position 2 24 W 47 V max 500mA const max 12
Position 3 25 W 47 V max 550mA const max 12
Position 4 32 W 46 V max 700mA const max 12
Position 5 20 W 24 V max 850mA const max 6/7
Position 6 20 W 22 V max 900mA const max 6/7
Position 7 10 W 10 V const 1050mA max -
Position 8 13 W 12 V const 1050mA max -
Position 9 20 W 24 V const 1050mA max -

Efficiency depending of the power: 20W - 32W : 84%  - 91%

TCI 122200 functions

For detailed description please refer to the data sheet.

Related links to "TCI MP 32 K2 - LED driver"
TCI LED driver 32W; constant currents: 350, 500, 550, 700, 850, 900mA  ; constant voltages... more
Features/tags of this product family. Please refer about the details in the description or datasheet.
Konstantspannung: 10V, 12V, 24V
Konstantstrom: 0,5A, 0,7A, 0,9A, 0,35A, 0,85A
Leistungsbereich: 5 - 20 W, 20 - 50 W
