Maxi Jolly US Casambi

109.94€ *
Net price: 92.39€

Prices incl. VAT plus shipping costs

Delivery time 6-12 weeks*


LED driver 60W - wirelessly dimmable via Casambi with dip-switch This is a DC LED driver from... more

LED driver 60W - wirelessly dimmable via Casambi with dip-switch

This is a DC LED driver from TCI that is dimmable with an integrated Casambi wireless module.
Selectable constant current, constant voltage via dip switch. The dimmable LED driver can be controlled by pressing a button (push button).
Switch on / off by pressing briefly. The brightness can be changed by a longer pressure.

Features of the LED driver:

  • Multipower driver supplied with dip-switch for the selection of the output current with integrated wireless CASAMBI modul
  • IP20 independent driver, for indoor
  • Class II protection against electric shock for direct or indirect contact
  • Active Power Factor Corrector
  • Analogical input (NTC) for thermal sensor connection
  • Auxiliary output 12 V max. 100 mA
  • Current regulation ±5 % including temperature variations
  • Input and output terminal blocks on the same side (wire cross-section up to 2,5 mm2 / AWG13)
  • Clamping screws on primary and secondary circuits for cables with diameter: min. 3 mm - max. 8 mm
  • Protections:
    • against overheating and short circuits
    • against mains voltage spikes
    • against overloads
  • Thermal protection = C.5.a
  • Flicker ( Output Ripple ) <= 3%

DIP-Switch Power Voltage out Current out
Position 1 25W 2...74 350mA const.
Position 2 35W 2...72 500mA const.
Position 3 39W 2...72 550mA const.
Position 4 46W 2...72 650mA const.
Position 5 50W 2...72 700mA const.
Position 6 54W 2...72 750mA const.
Position 7 60W 2...70 850mA const.
Position 8 60W 2...66 900mA const.
Position 9 60W 2...60 1,00A const.
Position 10 60W 2...57 1,05A const.
Efficiency as a function of power:> 92


Operation mode:

  • Light regulation 0/0,5 - 100 % by means of PUSH function a APP or compatible devices for CASAMBI integrated WIRELESS module
  • Light regulation 0/0,5 - 100 % by means of PUSH function (mains voltage):
    • A short push to turn on and off;
    • A longer push to increase or decrease light intensity;
    • Regulation automatically stops at minimum and maximum value;
    • For another on, regulation or off command, release the push button and give the desired command again;
    • Dimming level memory at mains restore
  • Possibility to use PUSH function to 4/5 drivers.
Check signal level when close to metal surfaces or inside metal box.

More information regarding the TCI Maxi Jolly US Casambi can be found in the data sheet in the Dowload tab.

Related links to "Maxi Jolly US Casambi"
LED Converter Maxi Jolly US Casambi; Vin110-240V; 0,35-1,05A; 25-60W; Vout 2-74V; Vout max 74V;... more
Features/tags of this product family. Please refer about the details in the description or datasheet.
·Constant Current: 0,5A, 0,7A, 0,9A, 0,35A, 0,55A, 0,65A, 0,75A, 0,85A, 1,0A, 1,05A
·Power range: 20 - 50 W, 50 - 100 W
·Dimmable/Control: Casambi radio, Linear/AM, Push-Button
#Kategoriefilter: LED-Treiber-alles mit CC
Data sheet Maxi Jolly US Casambi
