ATRIUM RONQ LED downlight 35W ZigBee/DALI DT8/Casambi

Product information "ATRIUM RONQ LED downlight 35W ZigBee/DALI DT8/Casambi"

PI-LED downlight ATRIUM RONQ 35W - dimming via DALI DT8 or NeoLink / ZigBee, up to IP54

This round recessed luminaire has PI-LED technology, which combines Tuneable White and RGB in one light source. This means that ATRIUM RONQ can cover a wide color temperature range from 1800 K to 16000 K and thus precisely reproduce the course of daylight. This is supported by the uniform light distribution that emanates from the luminaire. In addition, the LED downlight is very robust, which can be attributed to a high degree of protection up to IP54.

Another highlight are the innovative control options of the ATRIUM RONQ:

Product overview and features:

  • Round downlight with automatic daylight sequence
  • Matt reflector with diffuser
  • Soft light mixture and even light distribution
  • Range of functions: Color temperature 1,800 K to 16,000 K
  • High color locus stability thanks to microcontroller-controlled LED management
    • Temperature compensation
    • Factory calibration

Ordering data for ATRIUM RONQ:

The product is available in three different installation sizes. There is also the option of choosing between the ultra-modern control options DALI DT8, Casambi and ZigBee. Depending on the application (indoor / outdoor), versions with degrees of protection IP40 and IP54 are available.

Technical data:

DesignSmall (Ø 154 mm)Middle (Ø 204 mm)Large (Ø 254 mm)
light sourceLED module (PI-LED)
Operating voltage230 VAC
Performance20 W25 W35 W
Beam angle75 °82 °80 °
luminous flux1200 lm2000 lm2500 lm
Color temperature1800 K - 16000 K
Color rendering index (CRI)> 90
Control NeoLink / ZigBee
DALI DT8
Casambi
Dimming rangeCCT / CIE-xy 5-100%
RGB 0-100%
Degree of protectionIP40 or IP54
Protection classSKII
LifetimeL80 / B10 50000 h
Housing colorwhite (RAL 9003)
Assemblyinstallation
DimensionsØ 154 mm x 97 mm Ø 215 mm x 107 mm Ø 265 mm x 127 mm

Note:
The products of the manufacturer Kiteo are individually tailored to suit your needs. Made especially for you according to your specification. This also explains the longer delivery time of 1-3 weeks depending on the workload.

For more information, please refer to the data sheet in the download tab.

Properties "ATRIUM RONQ LED downlight 35W ZigBee/DALI DT8/Casambi"
·Application/IP-Code: IP4x, IP5x
·Color Temperature/Color: 2700K, 3000K, 3500K, 4000K, >5000K, Tuneable White
·Dimmable/Control: DALI DT8, Zigbee
Datasheet & further Infos about this product

Data sheet ATRIUM RONQ

DALI/ZigBee dimmable LED downlight

Manufacturer "KITEO GmbH"

KITEO lighting solutions revolve around the relationship between light and people, i.e. Ambience and a feel-good atmosphere take center stage and the lighting is based on your needs. KITEO makes use of the innovative PI-LED technology that unites Human Centric Lighting and brilliant RGB colour effects in one light source and brings daylight into every room while simulating the natural circadian daylight sequence.

Related links of the manufacturer

0 of 0 reviews

Average rating of 0 out of 5 stars

Leave a review!

Share your experiences with other customers.


In nachfolgenden FAQs finden sich weitere hilfreiche Informationen zur richtigen Auswahl

Recessed ceiling spotlights/downlights are available in many different versions. These parameters primarily define this product family:
  • Hole diameter - We recommend selecting the spots first, then drilling the holes. Otherwise the limitation is predetermined Output
  • Light output in lumens, or wattage. How much light is needed in the room. There is no general answer to this question. Use the following link for the project enquiry
  • Installation depth - usually a mandatory requirement in terms of drill hole depth or distance from suspended ceiling.
  • Color temperature dimmability - We recommend modern options such as DALI or Casambi.
  • Beam angle - For uniform room illumination. Usually determined by the distribution of the spots in the room and the room height.
  • Fastening - Installation in false ceiling or concrete ceiling Glare - Depending on the viewing angle, lower LEDs in the spotlight can often no longer be perceived as a bright point of light, thus ensuring pleasant lighting.

If you have a lighting project and would like to use downlights, please use the link provided for our project enquiry form. We will try to answer all your questions.

FAQ-Deckeneinbauspots
