Lux meter PCE-LED 20

€178.38*

net-price: €149.90

Prices incl. VAT plus shipping costs

Just 17 pieces available

Available, delivery time: 1-3 days*

Product number: PCE-LED 20

Manufacturer: PCE Deutschland GmbH

Manufacturer product number: PCE-LED 20

Weight: 0.32 kg

Min. order quantity: 1

Our benefits

Purchase and advice from the LED expert
Professional products from over 15 years of experience
LED technology is our passion
Free shipping for orders over €150 (DE)

Product information "Lux meter PCE-LED 20"

LED Lux meter PCE-LED 20

Fast and accurate light measurement / 2.5 measures per second / 1.5 meter sensor cable / Zero balance / Auto range / Battery powered handheld device/ Lux or footcandle measurement

An LED Lux meter is in use wherever a light check is necessary or recommended. The external light sensor of the LED Luxmeter can be positioned according to your needs. The cable of the sensor has an extended length of approx. 1.5 m / 4.9 ft. Different work or production processes require different lighting conditions. At the bottom of this page you will find recommendations for lighting conditions in schools, factories or offices.
The display of the illuminance can also be switched from lux to footcandle. The unit has only seven keys, allowing for one-hand operation. This also makes the instrument simple to use. The light sensor is located on a wound power cable, which hasan extended length of approx. 1.5 m / 4.9 ft.

Features of the PCE LED 20:

Ergonomically shaped light sensor
Displays measurements in lux or footcandle
Battery status indicator
Battery-saving automatic power off
Overload indicator
Wired sensor cable length of 1.5 m / 4.9 ft
MIN / MAX / AVG / HOLD functions
2.5 measurements per second
Zero adjustment
Automatic range selection

Technical data of the LED Luxmeter PCE-LED 20:

Measuring ranges	40 / 400 / 4000 / 40000 / 400000 lux 40 / 400 / 4000 / 40000 fc
Measuring units	Lux (lx) or footcandle (fc)
Sensor	Silicone photodiode with built-in filter
Display	Max. representation 3999 Representation of 40000 / 400000 lux and 40000 fc in klux and kfc respectively
Measuring accuracy	± 3% (for a standard incandescent lamp at 2856 K and LED white light) ± 6% for other visible light sources
Overload indication	OL = Overload
Internal memory	99 measured values
Measuring rate	2.5 x per second
Battery level indicator	yes
Measurable sources of light	LED and any other visible light
Measuring functions	Maximum / Minimum / Average / Hold / Zero Automatic balance Automatic shutdown Automatic range selection
Power supply	3 x 1,5 AAA batteries
Operating conditions	+5 ... +40 °C, 0 ... 70 % rF
Storage conditions	-10 ... +60 °C, 0 ... 70 % rF
For compliance with standards EMC	EMC:EN61326-1 (2006) IEC61000-4-2(2006) IEC61000-4-3(2006) + (2007) JIS C1609 : 1993 CNS 5519
Dimensions (L x W x H)	Approx. 162 x 62 x 28 mm / 6.4 x 2.5 x 1.1 in
Weight	Approx. 250 g /< 1 lb
Length of sensor cable	Approx. 1.5 m / 4.9 ft
Reproducibility	± 3 %
Recommended illuminance for different premises
Offices
Premises	Illuminance (Lux)
Offices, design rooms	1500 ... 750
Offices, meeting rooms, computer rooms	750 ... 300
Workrooms, corridors, staircases, toilets	300 ... 100
Escape stairs in the building	75 ... 30
Factory buildings
Premises	Illuminance (Lux)
Assembly rooms, testing stations, places for extremely precise optical work	3000 ... 1500
Assembly rooms, testing centers, places for precise optical work	1500 ... 750
Assembly rooms, testing stations, places for normal optical work	750 ... 300
Packing stations	300 ... 150
Escape stairs in the building	75 ... 30
School buildings
Premises	Illuminance (Lux)
Drawing rooms, laboratories with exact experiments	1500 ... 300
Classrooms, reading rooms in libraries, lounges, sports halls	750 ... 200
Lecture halls, meeting rooms, changing rooms, staircases, toilets	300 ... 75
Storage rooms, escape stairs	75 ... 30
School corridors	10 ... 2

Delivery scope:
1 x PCE-LED 20 LED lux meter
1 x Light sensor with protective cap
3 x Batteries
1 x Carrying case
1 x User manual

For further information as well as the manual please refer to the Download-Tab.

Datasheet & further Infos about this product

Data sheet PCE-LED 20
User manual PCE-LED 20
