LED DMX 512 Converter / Splitter / Amplifier 1 to 4 The LED DMX 512 splitter divides the DMX... more
LED DMX 512 Converter / Splitter / Amplifier 1 to 4The LED DMX 512 splitter divides the DMX bus into up to four DMX bus branches. The splitter works simultaneously as a signal amplifier. This is useful, for example, if individual DMX branches in a project are to be switched off..
The DMX bus should be terminated with a 120 Ohm resistor (not included).
|Input signal||1x DMX 512 Bus|
|Output signal||4x DMX 512 Bus|
|Input||1x terminal block or 1x XLR|
|Output||4x terminal block 4x XLR|
|Operating current||-30°C bis +55°C|
|Dimensions (LxWxH) in mm||ca. 192 x 80 x 41|
|Delivery scope||1x DMX 512Splitter Art.Nr. 767351213 |
incl. 12Vdc plug-in power supply unit
Note:This device must be installed by an electrician!
For further information please refer to the data sheet in the Download tab.
