CBU-TED Casambi Dimmer via phasecut

60.06€ * 66.73€ * (10% saved)
Net price: 50.47€

Prices incl. VAT plus shipping costs

Ready to ship today,
Delivery time appr. 1-3 workdays*


piece

Casambi Dimmer using phasecut CBU-TED High quality and compact phasecut-dimming CBU TED... more

Casambi Dimmer using phasecut CBU-TED

High quality and compact phasecut-dimming CBU TED by Casambi. It can be replaced with traditional
switch, only one installation in a switch case or a ceiling connection with lamps.


Bluetooth dimmer for actuating LED and halogen lamps

With your smartphone or tablet, you can dim lamps, actuate switches, create light scenes and form desired
lighting effects. You need only a BT 4.0 (2,4 GHz) connection and the appropriate app from Casambi.

The activation of the Casambi CBU-TED via BT 4.0 (2,4 GHz) saves complicated installation of cables.
The Bluetooth wireless Mesh-Network allows to control several lighting units.

You have lights or lamps and want instead a wall dimmer (trailing edge dimmer) to control the brightness
from your mobile phone? A Casambi dimmer like this one works instead of a wall dimmer. Connect the
Bluetooth dimmer between a switch and light lamps. Now you have a smart lighting control in your house.


Additional highlight:

Dimming the lights ALSO with your conventional light switch! That's how it works:

1. Switch on illumination with a usually switch.
2. Short (under 1 sec) off/on again. The illumination slowly dims up.
3. At the desired dimming value tip your swich again shortly off/on. The current dimming value is stored.
4. If the second tip off/on is not switched within 8 sec, the illumination dims up to 100%.


All product by Casambi family have following features:

  • Creates automatically a wireless Mesh-Network with other Casambi products.
  •  Wireless control using the free Casambi App for smartphones and tablets.
  • Integrate the use of regular wall switches for dimming and scene control.
  • Support for external on / off motion sensors.

These functions does the freed Casambi App:

  • Dimming of single or multiple lights with simple touch gestures.
  • Controlling the lighting of your stores, offices, or personal spaces.
  • Installation of single or complex scenarios with one or more lightings.
  • Define the security of the network. There are four different levels of security for access control.
  • Also support Philips HUE.


Specifications of Casambi CBU TED Bluetooth Unit:

 Input
 Input voltage  85-240VAC (50-60 HZ)
 Max. input voltage  0,65A
 Standby power  < 300mW
 Output
 Max. power

Incandescent and high voltage halogen bulbs:
150 W @ 230 VAC
High voltage AC LED modules:
150 W @ 230 VAC
Dimmable LED and CFL bulbs:
50 W @ 230 VAC
Dimmable electronic transformers:
50 W @ 230 VAC

max. Inrush Current 10 A(100ms)
must be observed!
 Minimum load requirement  1W
 Max. current  0,65A
 Radio transceiver
 Frequency range  2,4-2,483 GHz
 Max. output power  +4 dBm
 Mechanical data
 Dimensions  40,4 x 36,3 x 14,0 mm
 Weight  15 g
 Protection  IP20

For further technical data please refer to data sheet:



Compatible devices for Casambi App are:

iPhone iOS 10, IPad iOS 10 and Android 4.4-Version (KitKat) and all higher versions of the 3 named devices.

Download App for free:

QR code Casambi App in Appstore

Casambi App in Appstore

Casambi App iOS (iTunes)

QR Casambi App for Android

Casambi App for Android

Casambi App Android (Google Play)

CBU-TED overview


In this video, we’ll provide a brief overview of the CBU-TED and its features and functions.
Related links to "CBU-TED Casambi Dimmer via phasecut"
Casambi Dimmer Phasecut-dimming DBU-TED actuate with BT 4.0 (2,4 GHz) to dimming lights. more
Features/tags of this product family. Please refer about the details in the description or datasheet.
Application/IP-Code: IP20 - IP44 (Indoor)
Dimmable/Control: BT4.0 (2,4 GHz), Casambi radio, Phase-Cut (Triac)
Factsheet about CBU-TED
Specification and installation Guide Casambi dimmer CBU-TED
Instruction Casambi App
Casambi App iOS (iTunes)
Casambi App short description
Data sheet CBU-TED
