TCI Pro Flat DALI 26

45.94€ *
Net price: 38.61€

Prices incl. VAT plus shipping costs

Please select a variant first

Housing:


piece

DALI Pro Flat driver from TCI The TCI Pro Flat DALI 26 is a flat, electronic driver for... more

DALI Pro Flat driver from TCI

The TCI Pro Flat DALI 26 is a flat, electronic driver for direct current, whichis optionally controllable via DALI or button (Push-Switch-Button). Dimming takes place by amplitude modulation. Current is easily adjustable by dip switches.

Features of the driver (127576/127577)

  • Multipower driver supplied with dip-switch for the selection of the output current.
  • P20 independent driver, for indoor use (PRO FLAT DALI)
  • Class II protection against electric shock for direct or indirect contact (PRO FLAT DALI)
  • Driver for built-in use (PRO FLAT DALI BI)
  • It can be used for lighting equipment in protection class I and II (PRO FLAT DALI BI).
  • Clamping screws on primary and secondary circuits for cables with diameter: min. 2 mm - max. 9 mm (PRO FLAT DALI)
  • Protections:
    • against overheating and short circuit
    • against mains voltage spikes
    • against overloads.
  • Thermal protection = C.5.a

Operation mode

  • Features DALI-2 dimming (0/1 - 100 %, minimum output current 7 mA)
    • Memory function for sets or light groups
    • Recall of stored functions
    • Compatible with standard DALI interface
  • Dimming method is AMPLITUDE
  • Light regulation 0/1 - 100 % by means of PUSH SWITCH function (mains voltage)
  • A short push to turn on and off
  • A longer push to increase or decrease light intensity
  • Regulation automatically stops at minimum and maximum values
  • For another on, regulation or off command, release the push button and give the desired command again
  • Dimming level memory at mains restore
  • Keep enabled the SWITCH for at least 10 seconds to reset the dimming level to 30%
  • Keep enabled the SWITCH for at least 60 seconds to enable BILEVEL N function
    • keep pressed for 100% level
    • FADE OFF time is 30 seconds, light level 10%
    • PROLONG time is 30 minutes, then OFF
  • Switch off the driver for at least 5 seconds to disable the BILEVEL function


DALI2Push CurrentDiff
Ripple Free AMENEC


Dip-SW Power Voltage out Current out
Position 1 11,5 W 10...49V 250 mA const.
Position 2 13 W 10...49V 280 mA const.
Position 3 14,5 W 10...49V 310 mA const.
Position 4 15,5 W 10...48V 340 mA const.
Position 5 16,7 W 10...48V 370 mA const.
Position 6 18 W 10...47V 400 mA const.
Position 7 19,2 W 10...47V 430 mA const.
Position 8 20,5 W  10...47V 460 mA const.
Position 9 21,5 W 10...46V 490 mA const.
Position 10 22,8 W 10...46V 520 mA const.
Position 11 23,7 W 10...45V 550 mA const.
Position 12 24,5 W 10...44V 580 mA const.
Position 13 25,7 W 10...44V 610 mA const.
Position 14 26 W 10...41V 640 mA const.
Position 15 26 W 10...39V 670 mA const.
Position 16 26 W 10...37V 700 mA const.


IP20Built-in
For further information, please refer to our Download tab.
TCI Garantie

Related links to "TCI Pro Flat DALI 26"
Universal DALI2 compatible constant current driver in flat design with AM dimming. more
Features/tags of this product family. Please refer about the details in the description or datasheet.
Konstantstrom: 0,3A, 0,4A, 0,5A, 0,6A, 0,7A, 0,25A, 0,26A, 0,34A, 0,38A, 0,45A, 0,55A, 0,65A
Dimmbarkeit/Steuerung: DALI, DALI2, Linear/AM, Tast-Dimmen
Leistungsbereich: 5 - 20 W, 20 - 50 W
Data sheet Pro Flat DALI
