Meanwell PCD25 Powersupplies dimmable

19.40€ *
Net price: 16.30€

Prices incl. VAT plus shipping costs

Please select a variant first

Power / Constant Current:


piece

  • PCD-25-350B
  • PCD-25-350B
  • 0.22 kg
  • MEAN WELL
25W LED Converter for phase cut dimming The PCD series (Power Current Dimmable) stands for... more

25W LED Converter for phase cut dimming

The PCD series (Power Current Dimmable) stands for constant current sources, which can be used on the network side via conventional reverse phase control dimmer. In this way it is possible to operate with the PCD25, LED lamps for constant currents from 350mA to 1400mA back with commercially available wall dimmer.

Meanwell PCD constant current led driver



For example, swap halogen spotlights with LED spotlights constant current. Halogen transformer exchange against PCD25 by Meanwell and still control with conventional dimmer.

Features of PCD25 by Meanwell:

  • AC phase-cut dimming
  • Work with leading edge and trailing edge dimmers
  • 115VAC or 230VAC models available
  • Fully isolated plastic case
  • Constant current design
  • Protections: Short circuit / Overload / Over temperature
  • Built-in active PFC function
  • Cooling by free air convection
  • 100% full load burn-in test
  • High reliability
  • Suitable for indoor LED lighting applications
  • Low cost
  • 3 years warranty for all PCD25



Technical data PCD25 Meanwell

Parameter


operating condition
Min Typ Max
Input voltage primary Mains operation or operation via AC dimmer 180 V   295 V
Frequency range Mains frequency 47 Hz   63 Hz
AC current consumption 25°C, 230VAC at full load     0,3 A
Output voltage secondary

Type depends on - see data sheet

Output current

Depending on type and dimming.
Following options available:

  • PCD25-350B -> 350mA
  • PCD25-700B -> 700mA
  • PCD25-1050B -> 1050mA
  • PCD25-1400B -> 1400mA

More details see data sheet

Power input PCD-25 230VAC: Full load 20,3W    25,2W
Efficiency 230VAC: Full load   81 %
Operating by ambient temperature   - 30 °C   + 60°C
Conformity: CE, SELV,
EN61347-1
IEC 61347-2-13
IEC 55015
IEC 61000-3-2
Protection IP 42
Protection class SK II (Protect isolation)

Dimming, Compatibility:
Tested and compatible
to the manufacturer:

Details see data sheet

Lutron
Leviton
Berker
Jung
Clipsal
Bodo Ehmann Lichtregler
Dimensions 84mm x 57mm x 29,5 mm



Related links to "Meanwell PCD25 Powersupplies dimmable"
Meanwell PCD25 Series LED driver dimmable via phase or section control currents of 350mA -... more
Features/tags of this product family. Please refer about the details in the description or datasheet.
Application/IP-Code: IP20 - IP44 (Indoor)
Constant Current: 0,7A, 0,35A, 1,05A, 1,4A
Power range: 5 - 20 W, 20 - 50 W
Dimmable/Control: Phase-Cut (Triac)
Datasheet PCD25 Meanwell
Meanwell Installation Manual
